Moistureproof WPC Profile Production Line , Cabin Partition Profile
Extruder
Quick detail:
1. field:outdoor recreational equipment.traffic facilities,garden
decoration,construction,stair board,corridor,terrace,parking
room,outdoor pavilion,parapet wall,guardrail,trestle
2. product:pallet,wooden house,seat back,container
plate,baseboard,building template,moisture-proof
board,furniture,instrument panel,chair,tray,plank, cabin partition
table,promotion board,bench,skirting,dinning table
3.process type:extruding machine
4.feature:fire protection,moistureproof,water resistant,insect
resistant,non deformation
5.wood powder material: Straw, flax, peanut shells,etc
6.advantage:environmental product,plasticizing uniform,long life.
7.raw material:wood powder with PE/PP,PP/PE can be
recycled,additive material.
8.machine name:PP/PE WPC profile production line/extrusion machine/
9.wood powder: sawdust, saw powder, straw, wheat bran, rice husk
10.certification:CE,CSA,UL,ISO9001
11.documents:commercial invoice,packing list,certificate of
original,bill of lading,quality certificate,form E,form A,etc
12.type:WPC flower passage /corridor plastic profile extruder,wood
plastic composite seat table profile production machine.
13.screw type:double conical screw.
14.output:160-280kg/h
15.component:1).Automatic feeder,2).SJSZ65/132 Conical Twin Screw Extruder,3).SZD-4000 Vacuum sizing
table,4).SQY-240 hauling-off machine,5).SQG-240 cutting
machine,6).SFZ-6000 stacker
16.application:wood plastic composit profile
17.voltage:380V/3P/50HZ,600V/3P/60HZ,220V/3P/60HZ,or according to
customer’s requirement.
18. After-sales Service Provided: Engineers available to service
machinery overseas
19.mold:change molds to produce different profile products.
21.Minimum order:one set
22.application
area:packaging,decoration,construction,logistics,gardens,municipal
administration,traffic,sports,environmental
protection,military,home furnishing,children’s toys
23.wpc product type:hollow and solid
24.auxiliary machine:emboss machine,sanding machine,brushing
machine,etc.
Description:
PE/PP WPC Laminating Floor Plastic Profile Making Extruder
1.PE WPC floor profile is special for outdoor. This machine uses
the special designed screw and barrel, die and extrusion process to
produce plastic and wood products.
2.The series of products are: One step thick plastic and wood plate
extrusion machine, one step plastic and wood profile extrusion
machine, one step plastic and wood decoration plate extrusion
machine, plastic and wood pelletizing machine and different kinds
of plastic and wood dies.
3.This machine can use the one step extrusion method and also it
can use the two-step extrusion method after pelletizing. The
two-step extrusion method can save the power and space, and the
two-step extrusion method features the machine can gain the high
output and stable extrusion pressure.
4.A pre-heating feeder is mounted on the top of the extruder which
extracts the humidity from the wood powder, so that the feeding
section of the extruder can be filled with enough material and the
plastification effect will be better.
5.Special and well designed screw enables the raw material to be
evenly stay in the extruder. The screws and barrel are bi-metallic
treated, more wearable and anti-corrosion.
6.The machine can produce PE, PP or PVC and wood profile products.
These products are mainly applied for making pallets, packing
cases, floors, wall decoration materials and other wide
applications. The wood powder or plant fiber can be put up to max.
50-75%. This machine can produce the PP, PE, PVC, ABS, PS and etc
Applications:
1.field:outdoor,building,logistic,car,garden,home decoration,
2.product:plank floor,pavilion,chair,door,building
template,tray,rail crosstie,fence,courtyard handrail,flower pot.
3.machine type:wood plastic composite profile extruder machinery
4.green environment protection, waterproof, dampproof,
anti-corrosion, rot-resistence, ametabolic and good fire-retardant
5. Dimension(L*W*H):22m*2.5m*2.5m
6.main export place:north America,africa,Europe,southeast
asia,south America,etc
7. Available in different colors and wood grain design
8.Material is 100% recycled.
9. Complete process:
Milling → Mixing → Extruding → Mold → Calibrating → Hauling off→
Cutting→ Embossing,polishing,sanding→ Final product
Specifications:
Model | SJSZ65/132,SJSZ80/156,SJSZ92/188 |
usage | extrusion outdoor decorative |
raw material | recycled PE/PP,wood powder, additive material,etc |
product size | maximum:400mm,or according to prdroduct’s drawing |
Extruder feature | Special designed extruder |
wood powder ( wood fiber) | high volume of addition up to 50~75 percent |
Plastic proceed | PP,PE,PVC,wood plastic composite |
Auxiliary machine | Emboss machine,sanding machine,polishing machine |
Product type | Dustbin, Sound insulation board
(wall),edging,blinds,bulkhead,curtain rod, |
Competitive Advantage:
1.good after-service
2.spare parts are free
3.guarantee:one year or according to customer’s requirement.
4.advanced technology and best quality
5.international certification standard.
6.our engineer help and teach customer to test the machine.
